A Cost-Effective Lateral Solution for Smaller Fields
TWO WHeeled pivots
Features
Considering converting from flood, drip or side inlet irrigation? Our patented Valley® Two-Wheel Lateral is designed to meet the needs of smaller fields with your choice of how to feed water into the lateral cart: by ditch or hose. Lateral irrigation machines are a great choice for efficient irrigation, and may be the right fit for your field. Valley® lateral machines provide high return on investment compared to other irrigation equipment, including increased coverage and flexibility.
Maximize irrigated areas: Typically irrigates 92-98% of a square or rectangular field. Increase profitability: Helps reduce labor costs up to 50% compared to surface, side roll or hand move irrigation. Water conservation: Conserves water by applying the right amount of water when and where needed. Various applications: Does more than just irrigate; it can also be used for chemigation, fertigation, germination and leaching. Valley quality: Comes standard with made-in-the-USA Valley gearboxes, providing you with the reliability, durability and quality you expect from the industry leader.
SPECIFICATIONS
Maximum machine length: 1,300' Span length options: All available Pipe diameter options: 6 5/8" Pipeline choices: Galvanized, PolySpan® Hose option: Yes Ditch/canal option: Yes End feed option: Yes Center feed option: No Swing-around option: Yes Towable option: Yes GPS guidance: Yes Below-ground cable guidance: Yes Furrow guidance: Yes Above-ground cable guidance: Yes Modified alignment option: Yes Full floating alignment option: Yes Hose connections (I.D.): 4" & 6" (single) Auto-reverse on the hose: Standard Hose - HDPE: Yes Power supply: Cord drag, genset Cart-mounted pump: No Pump options: Cornell® Chemigation platform: Not available Water inlet: Not available Control panel options: AutoPilot Lateral, ClassicPlus
OPTIONS
Two Wheel Lateral Hose Feed
Towable from field to field in forward or reverse Skid-style suction inlet Available flow rates - 150 gpm to 1,105 gpm Soft and hard hose options available ranging from 4” to 6” (I.D.) Can be equipped with swing-around option
Two Wheel Lateral Ditch Feed
Take advantage of existing earthen ditches with the ditch feed option of our Valley Two-Wheel Lateral. You get all of the benefits of a small field lateral, as well as the ability to tow it or swing it around to cover more acres. Because this laterals flexible suction fits in nearly any functioning earth ditch, your investment will be kept low — no need to install a new container to hold your irrigation water. Can be equipped with swing-around option Towable from field to field, in forward or reverse Provides coverage for small and large fields Cart location available as end feed Cart Mounted Pump and skid-style suction inlet fits in nearly any earthen ditch Decreased labor inputs
